^TYPE

^{DISPLAY SKU}

^VOA040AN

^TYPE

^{Digital camera with support for interchangeable lenses}

^{LENS MOUNT}

^{Nikon Z mount}

^{PICTURE ANGLE}

^{Full-frame/FX-format}

^{IMAGE SENSOR}

^{SENSOR SIZE}

^{35.9 mm x 23.9 mm}

^{IMAGE SENSOR TYPE}

^CMOS

^{TOTAL PIXELS}

^{24.93 million}

^{DUST-REDUCTION SYSTEM}

^{Image Dust Off reference data (requires Capture NX-D); image sensor cleaning}

^{IMAGE AREA (PIXELS)}

^{FX 6,016 x 4,016 (Large) 4,512 x 3,008 (Medium) 3,008 x 2,008 (Small) DX 3,936 x 2,624 (Large) 2,944 x 1,968 (Medium) 1,968 x 1,312 (Small) Image Area 1:1 (24 x 24) 4,016 x 4,016 (Large) 3,008 x 3,008 (Medium) 2,000 x 2,000 (Small) Image Area 16:9 (36 x 20) 6,016 x 3,384 (Large) 4,512 x 2,536 (Medium) 3,008 x 1,688 (Small) Photographs taken while filming movies at a frame size of 3,840 x 2,160: 3,840 x 2,160 Photographs taken during movie recording at other frame sizes: 1,920 x 1,080: 1,920 x 1,080}

^{EFFECTIVE PIXELS (MEGAPIXELS)}

^{24.3 million}

^{IMAGE SENSOR FORMAT}

^{Full-frame/FX-format}

^{FILE SYSTEM}

^{FILE FORMAT STILL IMAGES}

^{NEF (RAW): 12 or 14 bit (lossless compressed or compressed) JPEG: JPEG-Baseline compliant with fine (approx. 1:4), normal (approx. 1:8), or basic (approx. 1:16) compression; size-priority and optimal-quality compression available NEF (RAW) + JPEG: Single photograph recorded in both NEF (RAW) and JPEG formats}

^{PICTURE CONTROL}

^{Auto Flat Landscape Monochrome Neutral Portrait Standard Vivid Creative Picture Controls: (Dream, Morning, Pop, Sunday, Somber, Dramatic, Silence, Bleached, Melancholic, Pure, Denim, Toy, Sepia, Blue, Red, Pink, Charcoal, Graphite, Binary, Carbon) Selected Picture Control can be modified Storage for custom Picture Controls}

^{FILE SYSTEM}

^{DCF 2.0 Exif 2.31}

^{STORAGE MEDIA}

^{SD (Secure Digital) and UHS-II compliant SDHC and SDXC memory cards}

^{CARD SLOT}

^{Dual Slots}

^VIEWFINDER

^VIEWFINDER

^{1.27 cm (0.5-in.) approx. 3690k-dot (Quad VGA) OLED with colour balance and auto and 11-level manual brightness controls}

^{EYE SENSOR}

^{Automatically switches between monitor and viewfinder displays}

^{COMPATIBLE LENSES}

^{Z mount NIKKOR lenses F mount NIKKOR lenses with mount adapter; restrictions may apply}

^{LENS COMPATIBILITY AT A GLANCE***}

^{Z mount NIKKOR lenses F mount NIKKOR lenses with mount adapter; restrictions may apply}

^{DEPTH-OF-FIELD CONTROL}

^Yes

^{REFLEX MIRROR}

^n/a

^{VIEWFINDER DIOPTER ADJUSTMENT}

^{-4 to +2 m-1}

^{VIEWFINDER EYEPOINT}

^{21 mm (-1.0 m-1; from center surface of viewfinder eyepiece lens)}

^{VIEWFINDER MAGNIFICATION}

^{Approx. 0.8x (50 mm lens at infinity, -1.0 m -1)}

^{VIEWFINDER FRAME COVERAGE}

^{Approx. 100% horizontal and 100% vertical}

^{FOCUSING SCREEN}

^n/a

^SHUTTER

^{SHUTTER TYPE}

^{Electronically-controlled vertical-travel focal-plane mechanical shutter; electronic front-curtain shutter; electronic shutter}

^{FRAME ADVANCE RATE}

^{Low-speed continuous: 1-4 fps High-speed continuous: 4.5 fps}

^{SHUTTER RELEASE MODES}

^{Single frame Low-speed continuous High-speed continuous Self-timer}

^{FLASH SYNC SPEED}

^{X=1/200 sec.; synchronizes with shutter at 1/200 sec. or slower; Auto FP High-Speed sync supported}

^{CONTINUOUS SHOOTING OPTIONS}

^{Low-speed continuous: 1-4 fps High-speed continuous: 4.5 fps}

^SELF-TIMER

^{2, 5, 10, 20 sec.; 1-9 exposures at intervals of 0.5, 1, 2, or 3 sec.}

^{FASTEST SHUTTER SPEED}

^{1/8000 sec}

^{TOP CONTINUOUS SHOOTING SPEED AT FULL RESOLUTION}

^{4.5 frames per second}

^EXPOSURE

^{EXPOSURE METERING}

^{TTL metering using camera image sensor}

^{EXPOSURE MODES}

^{Auto Programmed auto with flexible program (P) Shutter-priority auto (S) Aperture-priority auto (A) Manual (M) User settings (U1, U2, U3)}

^{EXPOSURE LOCK}

^{Luminosity locked at detected value}

^{EXPOSURE BRACKETING}

^n/a

^{EXPOSURE COMPENSATION}

^{-5 to +5 EV in increments of 1/3 or 1/2 EV available in modes P, S, A, and M}

^{SCENE MODES}

^n/a

^{EXPOSURE METER COUPLING}

^CPU

^{METERING RANGE}

^{Matrix or center-weighted metering: -3 to +17 EV (ISO 100, f/2.0 lens, 20 °C/68 °F)}

^{METERING METHOD}

^{Matrix metering Center-weighted metering: Weight of 75% given to 12 mm circle in center of frame; weighting can instead be based on average of entire frame Spot metering: Meters 4 mm circle (about 1.5% of frame) centered on selected focus point Highlight-weighted metering}

^{MIRROR LOCK UP}

^n/a

^SENSITIVITY

^{ISO SENSITIVITY}

^{ISO 100 - 51,200 in steps of 1/3 or 1/2 EV Can also be set to approx. 0.3, 0.5, 0.7 or 1 EV (ISO 50 equivalent) below ISO 100 or to approx. 0.3, 0.5, 0.7, 1 EV (ISO 102,400 equivalent) above ISO 51,200; auto ISO sensitivity control available}

^{SINGLE-POINT AF MODE}

^Yes

^{ACTIVE D-LIGHTING}

^{Can be selected from Auto, Extra High, High, Normal, Low, or Off}

^{EXPANDED ISO SENSITIVITY OPTIONS}

^n/a

^{HIGHEST EXPANDED ISO SENSITIVITY}

¹⁰²⁴⁰⁰

^{LOWEST EXPANDED ISO SENSITIVITY}

⁵⁰

^{HIGHEST STANDARD ISO SENSITIVITY}

⁵¹²⁰⁰

^{LOWEST STANDARD ISO SENSITIVITY}

¹⁰⁰

^{FOCUS / AUTOFOCUS}

^{FOCUS POINT}

^{273 (single-point AF) Number of focus points available in photo mode with single-point AF selected for AF-area mode and FX selected for image area}

^{TOP FP HIGH SPEED SYNC}

^{1/8000 sec.}

^{X-SYNC SPEED}

^{1/200th sec.}

^{BUILT-IN FLASH DISTANCE}

^n/a

^{FOCUS MODES}

^{Pinpoint Single-point Dynamic-area AF Wide-area AF (S) Wide-area AF (L) Auto-area AF Pinpoint and Dynamic-area AF available in photo mode only}

^{AF-AREA MODE}

^{Pinpoint Single-point Dynamic-area AF Wide-area AF (S) Wide-area AF (L) Auto-area AF Pinpoint and Dynamic-area AF available in photo mode only}

^{LENS SERVO}

^{Autofocus (AF): Single-servo AF (AF-S); continuous-servo AF (AF-C); full-time AF (AF-F; available only in movie mode); predictive focus tracking Manual focus (M): Electronic rangefinder can be used}

^{VR (VIBRATION REDUCTION) IMAGE STABILIZATION}

^{5-axis image sensor shift, lens shift available with VR lenses}

^{DETECTION RANGE}

^{-3 to +19 EV (without low-light AF: -2 to +19 EV) Measured in photo mode at ISO 100 and a temperature of 20 °C/68 °F using single-servo AF (AF-S) and a lens with a maximum aperture of f/2.0}

^{AUTOFOCUS SYSTEM}

^{Hybrid phase-detection/contrast AF with AF assist}

^{BUILTIN FLASH ZCAMERA}

^n/a

^{MAXIMUM AUTOFOCUS AREAS/POINTS}

²⁷³

^FEATURES

^{4K UHD, WiFi, Bluetooth}

^FLASH

^{FLASH COMPENSATION}

^{-3 to +1 EV in increments of 1/3 or 1/2 EV available in modes P, S, A, and M}

^{FLASH-READY INDICATOR}

^{Lights when optional flash unit is fully charged; flashes as underexposure warning after flash is fired at full output}

^{ACCESSORY SHOE}

^{ISO 518 hot-shoe with sync and data contacts and safety lock}

^{FLASH CONTROL}

^{TTL: i-TTL flash control; i-TTL balanced fill-flash is used with matrix, center-weighted, and highlight-weighted metering, standard i-TTL fill-flash with spot metering}

^{FLASH SYNC MODES}

^{Front-curtain sync Rear-curtain sync Red-eye reduction Red-eye reduction with slow sync Slow sync Off}

^{NIKON CREATIVE LIGHTING SYSTEM (CLS)}

^{i-TTL flash control, radio-controlled Advanced Wireless Lighting, optical Advanced Wireless Lighting, modeling illumination, FV lock, Color Information Communication, Auto FP High-Speed Sync, unified flash control}

^{FLASH SYNC TERMINAL}

^n/a

^{WHITE BALANCE}

^{WHITE BALANCE BRACKETING}

^Yes

^{LIVE VIEW SCENE AUTO SELECTOR}

^n/a

^{LIVE VIEW SHOOTING}

^{Photography Live View Mode Movie Live View Mode}

^MOVIE

^MOVIE

^{4K UHD 3,840x2,160 / 30 fps 4K UHD 3,840x2,160 / 25 fps 4K UHD 3,840x2,160 / 24 fps Full HD 1,920x1,080 / 60 fps Full HD 1,920x1,080 / 50 fps Full HD 1,920x1,080 / 30 fps Full HD 1,920x1,080 / 25 fps Full HD 1,920x1,080 / 24 fps Actual frame rates for 60p, 50p, 30p, 25p, and 24p are 59.94, 50, 29.97, 25, and 23.976 fps respectively Quality selection available at all sizes except 3,840 x 2,160 when quality is fixed at high}

^{MOVIE METERING}

^{TTL exposure metering using main image sensor}

^{TIME-LAPSE MOVIE}

^{Up to 4K UHD; Silent mode option}

^{MOVIE HDMI OUTPUT}

^{Yes Start/Stop supported}

^{MOVIE LOG GAMMA OUTPUT}

^n/a

^{TIME CODE}

^{Yes Drop frame}

^{MOVIE ACTIVE D-LIGHTING}

^{Can be selected from Auto, Extra High, High, Normal, Low, or Off}

^{MOVIE ISO}

^{M: Manual selection (ISO 100 to 25,600 in steps of 1/3 or 1/2 EV); auto ISO sensitivity control (ISO 100 to 25,600) available with selectable upper limit P, S, A: Auto ISO sensitivity control (ISO 100 to 25,600) with selectable upper limit Auto ISO sensitivity control (ISO 100 to 25,600)}

^{MOVIE AUDIO}

^{Built-in stereo or external microphone with attenuator option; sensitivity can be adjusted}

^{MOVIE AUDIO RECORDING FORMAT}

^{Linear PCM AAC}

^{MOVIE VIDEO COMPRESSION}

^{H.264/MPEG-4 Advanced Video Coding}

^{MOVIE FILE FORMAT}

^{MOV MP4}

^{MOVIE MAXIMUM RECORDING TIME}

^{29 minutes 59 seconds}

^{MOVIE FRAME SIZE (PIXELS) AND FRAME RATE}

^n/a

^{AF FOR MOVIE}

^{AF Speed and AF Tracking Sensitivity can be adjusted}

^MONITOR

^{MONITOR SIZE}

^{8 cm (3.2 in.) Diagonal}

^{MONITOR RESOLUTION}

^{1,040,000 dots}

^{MONITOR TYPE}

^{Tilting TFT Touch-Sensitive LCD}

^{MONITOR ANGLE OF VIEW}

^{170° viewing angle}

^{MONITOR ADJUSTMENTS}

^{Colour balance 11-level manual brightness controls}

^PLAYBACK

^{VOICE MEMO FUNCTION}

^n/a

^{IN-CAMERA IMAGE EDITING}

^{Distortion Control D-Lighting Image Overlay NEF (raw) Processing Perspective Control Red-eye Reduction Resize Side by Side Comparison Straighten Trim Trim Movie}

^{PLAYBACK FUNCTIONS}

^{Auto Image Rotation Full-frame and thumbnail (4, 9, or 72 images or calendar) Highlights Histogram Display Location Data Display Movie Playback Photo and/or Movie Slide Shows Photo Information Picture Rating Playback with Playback Zoom Playback Zoom Cropping}

^INTERFACE

^INTERFACE

^{USB: Type C connector (SuperSpeed USB) HDMI: Type C HDMI connector Accessory terminal: Can be used with MC-DC2 and other optional accessories Audio Input: Stereo mini-pin jack (3.5 mm diameter; plug-in power supported) Audio Output: Stereo mini-pin jack (3.5 mm diameter)}

^{WI-FI FUNCTIONALITY}

^{Standards: IEEE 802.11b/g/n/a/ac 2412–2462 MHz (channel 11) and 5180–5825 MHz (U.S.A., Canada, Mexico) 2412–2462 MHz (channel 11) and 5180–5805 MHz (other countries in the Americas) Maximum output power (EIRP): 2.4 GHz band: 7.4 dBm 5 GHz band: 12.2 dBm Authentication: Open system, WPA2-PSK}

^GPS

^{Via the SnapBridge app}

^{TOTAL CUSTOM SETTINGS}

³⁸

^MENUS

^{SUPPORTED LANGUAGES}

^{English French Portuguese (Brazil) Spanish The languages available vary with the country or region in which the camera was originally purchased.}

^{DATE, TIME AND DAYLIGHT SAVINGS TIME SETTINGS}

^Yes

^{WORLD TIME SETTING}

^Yes

^POWER

^{BATTERY / BATTERIES}

^{One EN-EL15c rechargeable Li-ion battery EN-EL15b/EN-EL15a/EN-EL15 batteries can also be used. Note, however, that fewer pictures can be taken on a single charge than with the EN-EL15c. The EH-7P charging AC adapter can be used to charge EN-EL15c/EN-EL15b batteries only.}

^{BATTERY LIFE (SHOTS PER CHARGE)}

^{[Viewfinder only]: Approx. 390 shots [Monitor only]: Approx. 470 shots [Viewfinder only]: Approx. 115 minutes of movie recording [Monitor only] : Approx. 120 minutes of movie recording}

^{AC ADAPTER}

^{EH-7P Charging AC Adapter EH-5d/EH-5c/EH-5b AC adapter (requires EP-5B power connector, available separately)}

^{BATTERY CHARGER}

^{MH-25A Battery Charger}

^{MISCELLANEOUS}

^{WEIGHT (G) (BODY ONLY)*1}

^{Approx. 590 g (20.9 oz.) camera body only}

^{LENGTH X HEIGHT X WIDTH (MM) (BODY ONLY)*}

^{134 mm x 100.5 mm x 69.5 mm (5.3 in. x 4.0 in. x 2.8 in.)}

^{TRIPOD SOCKET}

^{0.635 cm (1/4 in., ISO 1222)}

^{ANIMAL EYE AF}

⁰

^{4K UHD}

^Yes

^WIFI

^Yes

^BLUETOOTH

^Yes
