LENS MOUNT

E-mount

WEIGHT (MAIN UNIT ONLY) (approx.)

890 g (1 lb 15 oz)

WEIGHT (INCLUDING SUPPLIED ACCESSORIES) (approx.)

2.59 kg (5 lb 11 oz) (with Viewfinder, Grip Remote Control, BP-U35 battery, SEL24105G LENS, Lens Hood, Handle, MIC holder)

DIMENSIONS (W X H X D) (BODY WITHOUT PROTRUSIONS) (approx.)

114 x 116 x 153 mm (4.49 x 4.57 x 6.02) (body without protrusions)

POWER REQUIREMENTS

DC 19.5 V

POWER CONSUMPTION

Approx. 18.0 W (while recording XAVC-I QFHD 59.94p, SEL24105G Lens, Viewfinder ON, not using external device)

BATTERY OPERATING TIME

Approx. 105 min. with BP-U35 battery (while recording XAVC-I QFHD 59.94p, SEL24105G Lens, Viewfinder ON, not using external device)

Approx. 215 min. with BP-U70 battery (while recording XAVC-I QFHD 59.94p, SEL24105G Lens, Viewfinder ON, not using external device)

OPERATING TEMPERATURE

0 °C to 40 °C (32 °F to 104 °F)

STORAGE TEMPERATURE

–20 °C to +60 °C (–4 °F to +140 °F)

XAVC INTRA

XAVC-I DCI4K 59.94p mode: VBR, MAX bit rate 600 Mbps, MPEG-4 AVC/H.264

XAVC-I DCI4K 50p mode: VBR, MAX bit rate 500 Mbps, MPEG-4 AVC/H.264

XAVC-I DCI4K 29.97p mode: VBR, MAX bit rate 300 Mbps, MPEG-4 AVC/H.264

XAVC-I DCI4K 25p mode: VBR, MAX bit rate 250 Mbps, MPEG-4 AVC/H.264

XAVC-I DCI4K 24p mode: VBR, MAX bit rate 240 Mbps, MPEG-4 AVC/H.264

XAVC-I DCI4K 23.98p mode: VBR, MAX bit rate 240 Mbps, MPEG-4 AVC/H.264

XAVC-I QFHD 59.94p mode: VBR, MAX bit rate 600 Mbps, MPEG-4 AVC/H.264

XAVC-I QFHD 50p mode: VBR, MAX bit rate 500 Mbps, MPEG-4 AVC/H.264

XAVC-I QFHD 29.97p mode: VBR, MAX bit rate 300 Mbps, MPEG-4 AVC/H.264

XAVC-I QFHD 25p mode: VBR, MAX bit rate 250 Mbps, MPEG-4 AVC/H.264

XAVC-I QFHD 23.98p mode: VBR, MAX bit rate 240 Mbps, MPEG-4 AVC/H.264

XAVC-I HD 59.94p mode: CBG, MAX bit rate 222 Mbps, MPEG-4 AVC/H.264

XAVC-I HD 50p mode: CBG, MAX bit rate 223 Mbps, MPEG-4 AVC/H.264

XAVC-I HD 29.97p mode: CBG, MAX bit rate 111 Mbps, MPEG-4 AVC/H.264

XAVC-I HD 25p mode: CBG, MAX bit rate 112 Mbps, MPEG-4 AVC/H.264

XAVC-I HD 23.98p mode: CBG, MAX bit rate 89 Mbps, MPEG-4 AVC/H.264

XAVC LONG

XAVC-L QFHD 29.97p/25p/23.98p mode: VBR, MAX bit rate 100 Mbps, MPEG-4 H.264/AVC

XAVC-L QFHD 59.94/p/50p mode: VBR, MAX bit rate 150 Mbps, MPEG-4 H.264/AVC

XAVC-L HD 29.97p/25p/23.98p/59.94p/50p mode: VBR, MAX bit rate 50 Mbps, MPEG-4 H.264/AVC

XAVC-L HD 29.97p/25p/23.98p/59.94p/50p mode: VBR, MAX bit rate 35 Mbps, MPEG-4 H.264/AVC

RECORDING FORMAT (AUDIO)

LPCM 24 bits, 48 kHz, 4 channels

XAVC INTRA

XAVC-I DCI4K mode: 4096 x 2160/59.94P, 50P, 29.97P, 23.98P, 25P, 24P

XAVC-I QFHD mode: 3840 x 2160/59.94P, 50P, 29.97P, 23.98P, 25P

XAVC-I HD mode: 1920 x 1080/59.94P, 50P, 29.97P, 23.98P, 25P

XAVC LONG

XAVC-L QFHD mode: 3840 x 2160/59.94P, 50P, 29.97P, 23.98P, 25P

XAVC-L HD 50 mode: 1920 x 1080/59.94P, 50P, 29.97P, 23.98P, 25P

XAVC-L HD 35 mode: 1920 x 1080/59.94P, 50P, 29.97P, 23.98P, 25P

XAVC INTRA

XAVC-I DCI4K/QFHD 59.94p When using CEA-G160T (160 GB): Approx. 30 minutes When using CEA-G80T (80 GB): Approx. 15 minutes

XAVC-I DCI4K/QFHD 50p When using CEA-G160T (160 GB): Approx. 36 minutes When using CEA-G80T (80 GB): Approx. 17 minutes

XAVC-I DCI4K/QFHD 29.97p When using CEA-G160T (160 GB): Approx. 60 minutes When using CEA-G80T (80 GB): Approx. 29 minutes

XAVC-I DCI4K/QFHD 25p When using CEA-G160T (160 GB): Approx. 71 minutes When using CEA-G80T (80 GB): Approx. 35 minutes

XAVC-I DCI4K 24p When using CEA-G160T (160 GB): Approx. 74 minutes When using CEA-G80T (80 GB): Approx. 36 minutes

XAVC-I DCI4K/QFHD 23.98p When using CEA-G160T (160 GB): Approx. 74 minutes When using CEA-G80T (80 GB): Approx. 36 minutes

XAVC-I HD 59.94p When using CEA-G160T (160 GB): Approx. 78 minutes When using CEA-G80T (80 GB): Approx. 38 minutes

XAVC-I HD 50p When using CEA-G160T (160 GB): Approx. 78 minutes When using CEA-G80T (80 GB): Approx. 38 minutes

XAVC-I HD 29.97p When using CEA-G160T (160 GB): Approx. 150 minutes When using CEA-G80T (80 GB): Approx. 74 minutes

XAVC-I HD 25p When using CEA-G160T (160 GB): Approx. 150 minutes When using CEA-G80T (80 GB): Approx. 74 minutes

XAVC-I HD 23.98p When using CEA-G160T (160 GB): Approx. 185 minutes When using CEA-G80T (80 GB): Approx. 91 minutes

XAVC LONG

XAVC-L QFHD 29.97p/25p/23.98p When using CEA-G160T (160 GB): Approx. 170 minutes When using CEA-G80T (80 GB): Approx. 86 minutes

XAVC-L QFHD 59.94p/50p When using CEA-G160T (160 GB): Approx. 115 minutes When using CEA-G80T (80 GB): Approx. 57 minutes

XAVC-L HD 50 /29.97p/25p/23.98p/59.94p/50p When using CEA-G160T (160 GB): Approx. 320 minutes When using CEA-G80T (80 GB): Approx. 155 minutes

XAVC-L HD 35 29.97p/25p/23.98p/59.94p/50p When using CEA-G160T (160 GB): Approx. 430 minutes When using CEA-G80T (80 GB): Approx. 210 minutes

PROXY AUDIO

XAVC Proxy: AAC-LC, 128 kbps, 2 channels

PROXY VIDEO

XAVC Proxy: AVC/H.264 High Profile 4:2:0 Long GOP, VBR 1920 x 1080, 9 Mbps

SENSOR TYPE

35 mm full-frame, single-chip CMOS image sensor

PIXELS

Approx. 12.9 megapixels (total), Approx. 10.2 megapixels (effective)

BUILT-IN OPTICAL FILTERS

Clear, linear variable ND (1/4 ND to 1/128 ND)

SENSITIVITY

ISO 800/12800 (Cine EI mode, D55 Light source)

SIGNAL TO NOISE RATIO

delete

SHUTTER SPEED

64F to 1/8000 sec

XAVC-I

4096 x 2160

1 to 60 frames (59.94/50/29.97/25/24/23.98)

XAVC-I/L

3,840 x 2,160

1 to 60, 100, 120 frames (59.94/50/29.97/25/23.98)

1920 x 1080

1 to 60, 100, 120, 150, 180, 200, 240 frames (59.94/50/29.97/25/23.98)

WHITE-BALANCE MODES

Preset, Memory A, Memory B (2,000 K–15,000 K)/ATW

GAIN CONTROL

–3 to 30dB (every 1dB), AGC

GAMMA CURVE

SDR mode: S-Cinetone, Standard, Still, ITU709, HDR mode: HLG_Live, HLG_Natural

Latitude

15+ stop

TC INPUT/TC OUTPUT

BNC, TC IN/OUT Switchable

AUDIO INPUT

XLR-type 3-pin (female) (x2), line/mic/mic +48 V selectable

Mic Reference: –30 to –80 dBu

SDI OUTPUT

SDI OUT: BNC, 12G-SDI, 6G-SDI, 3G-SDI(Level A/B)

USB

USB Type-C (x1), Multi/Micro-B (x1)

HEADPHONE OUTPUT

Stereo mini jack (x1)

–16 dBu 16 Ω

SPEAKER OUTPUT

Monaural

DC INPUT

DC jack

HDMI OUTPUT

Type A (x1)

REMOTE

Stereo mini-minijack (Φ2.5 mm)

GRIP

Minijack (φ3.5 mm / 4 pin)

MEDIA TYPE

CFexpress Type A / SD card (x2)

Slot B can be used for saving configuration data.

LCD

8.8 cm (3.5 type)

Approx. 2.76 M dots

BUILT-IN MICROPHONE

Omni-directional monoral electret condenser microphone (body) (x1)

Stereo electret condenser microphone (handle) (x1)

SUPPORTED FORMAT

IEEE 802.11 a/b/g/n/ac

FREQUENCY BAND

2.4 GHz bandwidth

5.2/5.3/5.6/5.8 GHz bandwidth

SECURITY

WEP/WPA-PSK/WPA2-PSK

NFC

NFC Forum Type 3 Tag compliant

SUPPLIED ACCESSORIES

Handle (1)

LCD monitor (1)

Grip remote control (1)

AC adaptor (1)

Power cord (1)

Battery charger (1)

Battery pack (1)

USB-C cable (1)

LCD hood (1)

Cold shoe kit (1)

Lens mount cap (1)

Handle connector cap (1)

Before Using This Unit (1)
