Add a powerful PTZ camera setup with HD video capture to your production with this PTZ1271-20X-POE Full HD PTZ Camera from AVMatrix. The camera offers precision control and multiple output ports offering up to 1080p video, and it also supports control and streaming over LAN. Designed for broadcast, security, and teleconferencing needs, the PTZ1271-20X-POE also supports VISCA, PELCO-D, and PELCO-P control protocols.
The integrated f/1.6 to 3.5 lens offers 20x optical and 10x digital zoom functions. This camera supports video output via HDMI and 3G-SDI and has a LAN port for streaming via RTMP, RTSP, or ONVIF. Power this PTZ camera using the the included 12 VDC adapter or via PoE. Quick pan and tilt speeds and picture controls like brightness, color, saturation, contrast, sharpness, and 2D/3D Noise Reduction provide precision control of your images.
Technical Specifications:
Image Sensor
1/2.8"-Type CMOS
Sensor Resolution
Effective: 2.07 Megapixel
Built-In ND Filter
No
Focus Control
Autofocus
Signal-to-Noise Ratio
55 dB
Flip / Mirror Support
Image Flip
White Balance
3000 to 7000K
Focal Length
5.5 to 110mm
Optical Zoom Ratio
20x
Max Digital Zoom
10x
Field of View
54.7 to 3.3°
Maximum Aperture
f/1.6 to 3.5
External Recording Modes
SDI/BNC / HDMI
1920 x 1080p
Broadcast Output
NTSC
IP Streaming
RTMP, RTSP, SRT
1920 x 1080
Presets
255
Move Speed
Pan: 0.1 to 180°/sec
Tilt: 0.1 to 80°/sec
Movement Range
Pan: 340° (-170 to 170°)
Tilt: 120° (-30 to 90°)
Supported Control Protocols
Pelco-D
Pelco-P
VISCA
Video I/O
1 x BNC (3G-SDI) Output
1 x HDMI Output
Audio I/O
1 x 1/8" / 3.5 mm TRS Stereo Line Input
Other I/O
1 x RJ45 (LAN)
1 x Mini-DIN 8-Pin (RS-232) Input
1 x Mini-DIN 8-Pin (RS-232) Output
1 x Block (RS-485) Input
PoE Support
PoE 802.3af
Power I/O
1 x Barrel Input
Power Consumption
Device: 12 VDC at 1 A (12 W)
Operating Temperature
14 to 122°F / -10 to 50°C
Storage Temperature
14 to 140°F / -10 to 60°C
Operating Humidity
20 to 80% (Non-Condensing)
Storage Humidity
20 to 95% (Non-Condensing)
Mounting
1 x 1/4"-20 Female for Tripod
Dimensions (W x H x D)
6.7 x 7.1 x 6.7" / 170 x 180.31 x 170 mm
Weight
2.76 lb / 1.25 kg
