Input

1 x BNC (3G-SDI / HD-SDI / SD-SDI) Female

Embedded Audio

SDI

Output

4 x BNC (3G-SDI / HD-SDI / SD-SDI) Female

Video Standard Compliance

SMPTE 259M/292M/296M/372M/424M/425M

Reclocking

Yes

HDR Compatibility

No

HDCP Support

No

EDID Support

No

Video Format

SDI Input (10/12-Bit 4:4:4/4:2:2 RGB, YUV)

DCI 2K: 23.98/24/25/29.97/30 fps

DCI 2KPsF: 23.98/24/25/29.97/30 fps

1080p: 23.98/24/25/29.97/30/50/59.94/60 fps

1080PsF: 23.98/24/25/29.97/30 fps

1080i: 50/59.94/60 fps

720p: 50/59.94/60 fps

PAL: 50 fps

NTSC: 59.94 fps

Power Connector

1 x Micro-USB (5 VDC) Input

Power Consumption

Device: 5 to 17 VDC (1 W)

ESD Protection

No

Operating Temperature

-4 to 140°F / -20 to 60°C

Storage Temperature

-22 to 158°F / -30 to 70°C

Operating Humidity

0 to 90% (Non-Condensing)
